Description
Benefits
- Optimum lamp lifetime compared with electromagnetic gear circuits is achieved in applications with long burning hours (IEC cycle)
- Energy savings of more than 25% (at equal luminous flux) compared with electromagnetic gear
- Enhanced design freedom thanks to compact form
Features
- Warm start: (EBS 114 & EBS118) flicker-free start, ideal for lighting applications up to 25 W
- Multi-lamp ballast: one ballast can be used to drive lamps of different types and wattages
General Information
- Design Square Housing
- Automatic Restart Yes
Operating and Electrical
- Input Voltage 220 to 240 V
- Input Frequency 50 to 60 Hz
- Operating Frequency (Min) 42 kHz
- Ignition Method Warm Start
- Crestfactor (Max) 1.85
- Power Factor 100% Load (Nom) 0.6
- Ignition Time (Max) 1 s
- Mains Voltage Performance (AC) 221-254V
- Mains Voltage Safety (AC) 216-264V
- Power Losses (Nom) 3.5 W
Wiring
- Connector Type Input Terminals WAGO 251 universal connector [ Suitable for both automatic wiring (ALF and ADS) and manual wiring]
- Connector Type Output Terminals WAGO 251 universal connector [ Suitable for both automatic wiring (ALF and ADS) and manual wiring]
- Wire Striplength 9.0-10.0 mm
- Input Terminal Cross Section 0.50-1.50 mm²
- Output Terminal Cross Section 0.50-1.50 mm²
System characteristics
- Rated Ballast-Lamp Power 14 W
Temperature
- T-Ambient (Max) 40 °C
- T-Ambient (Min) 0 °C
- T-Storage (Max) 85 °C
- T-Storage (Min) -40 °C
- T-Case Maximum (Max) 75 °C
- T-Ignition (Min) 0 °C
- Emergency Operation
- Battery Voltage Lamp Ignition 198-254 V
- Battery Voltage Lamp Operation 176-254
- Approval and Application
- EMC Immunity Standard IEC 61547
- Humidity Standard IEC 61347-2-3 clause 11
- Hum And Noise Level Inaudible
- Net Weight (Piece) 0.040 kg
